HP EliteBook 1020 G2 - 1EP69EA
HP EliteBook 1020 G2
Product code: 1EP69EA
- 💻Display diagonal: 12.5 inch
- 🔳Processor model: i5-7200U
- 🎫Internal memory: 8 GB
- 🎮On-board graphics adapter model: Intel HD Graphics 620
- 🎮Discrete graphics adapter model: Not available
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 1.13 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Colour of product | Silver |
| Product type | Notebook |
| Form factor | Clamshell |
| Intel® vPro™ Platform Eligibility | N |
| Display | |
| Display diagonal | 12.5 inch |
| Panel type | IPS |
| Display surface | Matt |
| Aspect ratio | 16:9 |
| 3D | N |
| HD type | Full HD |
| LED backlight | Y |
| Touchscreen | Y |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Brand | HP |
| Family | EliteBook |
| Series | 1000 |
| Model name | 1020 G2 |
| Part Number | 1EP69EA |
| Release Date | 01 October 2017 |
| EAN/UPC code | 0192018046542, 192018046542, 0192018288843, 192018288843, 0191628858385, 191628858385, 0191628862351, 191628862351, 0191628974849, 191628974849, 0192018046924, 192018046924, 0191628878574, 191628878574, 0192018309005, 192018309005, 0191628871766, 191628871766, 0192545038546, 192545038546, 0192018732971, 192018732971, 0192545387637, 192545387637, 0192545387651, 192545387651, 0193424759682, 193424759682, 0191628878567, 191628878567 |
| Price | About 2186 USD |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i5 |
| Processor frequency | 2.5 GHz |
| Processor boost frequency | 3.1 GHz |
| Processor codename | Kaby Lake |
| Thermal Design Power (TDP) | 15 W |
| Processor model | i5-7200U |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor cache | 3 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1356 |
| Configurable TDP-up frequency | 2.7 GHz |
| Configurable TDP-up | 25 W |
| Processor generation | 7th gen Intel Core i5 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 8 GB |
| Memory clock speed | 1866 MHz |
| Memory layout (slots x size) | 1 x 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter DirectX version | 12.0 |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel HD Graphics 620 |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter base frequency | 300 MHz |
| On-board graphics adapter dynamic frequency (max) | 1000 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics card | Y |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel HD Graphics 620 |
| On-board graphics card family | Intel HD Graphics |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1000 MHz |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x5916 |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | NVMe 3.0, PCI Express |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Solid-state drive interface | NVMe 3.0, PCI Express |
| Solid-state drive capacity | 512 GB |
| Card reader integrated | N |
| Storage media | SSD |
| NVMe | Y |
| Optical drive | |
| Optical drive type | N |
| Networking | |
| Ethernet LAN | N |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 5 (802.11ac) |
| Bluetooth | Y |
| Bluetooth version | 4.2 |
| Near Field Communication (NFC) | Y |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| Charging port type | DC-in jack |
| Microphone in | N |
| S/PDIF out port | N |
| DVI port | N |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 2 |
| Combo headphone/mic port | Y |
| DC-in jack | Y |
| HDMI ports quantity | 1 |
| Audio | |
| Built-in microphone | Y |
| Number of built-in speakers | 2 |
| Camera | |
| Front camera | Y |
| Keyboard | |
| Numeric keypad | N |
| Spill-resistant keyboard | Y |
| Spill resistant keyboard | Y |
| Keyboard backlit | Y |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 4 |
| Battery capacity | 49.28 Wh |
| Battery capacity (Watt hours) | 49.28 Wh |
| Weight & dimensions | |
| Weight | 1.13 kg |
| Height | 13.9 mm |
| Depth | 203.8 mm |
| Width | 290 mm |
| Power | |
| AC adapter power | 65 W |
| Security | |
| Trusted Platform Module (TPM) | Y |
| Password protection | Y |
| Password protection type | Power on |
| Brand-specific features | |
| HP Management tools | HP BIOSphere, HP DriveLock, HP Sure Start, HP Client Security, HP Driver Packs, HP System Software Manager, HP BIOS Config Utility, HP Client Catalog, HP Management Integration |
| HP segment | Business |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
