HP Elite Dragonfly - 8MK77EA
HP Elite Dragonfly
Product code: 8MK77EA
- 💻Display diagonal: 13.3 inch
- 🔳Processor model: i7-8565U
- 🎫Internal memory: 16 GB
- 🎮On-board graphics adapter model: Intel UHD Graphics 620
- 🎮Discrete graphics adapter model: Not available
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 0.99 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Product type | Hybrid (2-in-1) |
| Form factor | Convertible (Folder) |
| Intel® vPro™ Platform Eligibility | N |
| Display | |
| Display diagonal | 13.3 inch |
| Dual-screen | N |
| NTSC coverage (typical) | 72% |
| Display bezel technology | Micro-Edge |
| Display brightness | 400 cd/m² |
| Panel type | IPS |
| Touch technology | Multi-touch |
| Aspect ratio | 16:9 |
| HD type | Full HD |
| LED backlight | Y |
| Touchscreen | Y |
| Display resolution | 1920 x 1080 pixels |
| RGB colour space | NTSC |
| Colour gamut | 72% |
| Native aspect ratio | 16:9 |
| Brand | HP |
| Family | Elite |
| Model name | Dragonfly |
| Part Number | 8MK77EA |
| Release Date | 01 December 2019 |
| EAN/UPC code | 0194721343857, 194721343857, 0194721343406, 194721343406, 0194721344649, 194721344649, 0194721344700, 194721344700, 0194721344762, 194721344762, 0194721344823, 194721344823, 0194721344861, 194721344861, 0194721344878, 194721344878, 0194721344892, 194721344892, 0194721343802, 194721343802, 0194721343895, 194721343895, 0194721343932, 194721343932, 0194721343970, 194721343970, 0194721344021, 194721344021, 0194721344076, 194721344076, 0194721344120, 194721344120, 0194721344175, 194721344175, 0194721344205, 194721344205, 0194721344281, 194721344281, 0194721344335, 194721344335, 0194721414694, 194721414694, 0194721344366, 194721344366, 0194721344403, 194721344403, 0194721344458, 194721344458, 0194721344489, 194721344489, 0194721344571, 194721344571, 0194721344243, 194721344243, 0194721587268, 194721587268, 0194721344526, 194721344526 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor frequency | 1.8 GHz |
| Processor boost frequency | 4.6 GHz |
| Processor codename | Whiskey Lake |
| Thermal Design Power (TDP) | 15 W |
| Processor model | i7-8565U |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor cache | 8 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1528 |
| Configurable TDP-up frequency | 2 GHz |
| Configurable TDP-up | 25 W |
| Processor generation | 8th gen Intel Core i7 |
| Memory | |
| Internal memory type | LPDDR3-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2133 MHz |
| Memory slots | 1x SO-DIMM |
| ECC | N |
| Graphics | |
| On-board graphics adapter | Y |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel UHD Graphics 620 |
| Discrete graphics adapter model | Not available |
| On-board graphics card | Y |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel UHD Graphics |
| On-board graphics card family | Intel UHD Graphics |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3EA0 |
| Storage | |
| Total storage capacity | 512 GB |
| Intel® Optane™ Memory module installed | Y |
| Intel® Optane™ Memory module capacity | 32 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | PCI Express, NVMe |
| Card reader integrated | N |
| Storage media | SSD |
| Intel® Optane™ Memory module installed | Y |
| Intel® Optane™ Memory module capacity | 32 GB |
| NVMe | Y |
| Optical drive | |
| Optical drive type | N |
| Networking | |
| Ethernet LAN | N |
| Wi-Fi | Y |
| WLAN controller model | Intel Wi-Fi 6 AX200 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Bluetooth | Y |
| Bluetooth version | 5.0 |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| HDMI version | 1.4 |
| USB Sleep-and-Charge ports | 1 |
| Combo headphone/mic port | Y |
| HDMI ports quantity | 1 |
| Thunderbolt 3 ports quantity | 2 |
| USB Sleep-and-Charge | Y |
| Audio | |
| Built-in microphone | Y |
| Number of built-in speakers | 4 |
| Audio system | Bang & Olufsen |
| Camera | |
| Front camera | Y |
| Keyboard | |
| Numeric keypad | N |
| Spill-resistant keyboard | Y |
| Keyboard special features | Morsbestendig |
| Spill resistant keyboard | Y |
| Pointing device | Clickpad |
| Performance | |
| Accelerometer | Y |
| Gyroscope | Y |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery weight | 220 g |
| Number of battery cells | 2 |
| Battery capacity | 38 Wh |
| Battery capacity (Watt hours) | 38 Wh |
| Weight & dimensions | |
| Weight | 0.99 kg |
| Height | 16.1 mm |
| Depth | 197.5 mm |
| Width | 304.3 mm |
| Power | |
| AC adapter power | 65 W |
| Security | |
| Trusted Platform Module (TPM) | Y |
| Brand-specific features | |
| HP Management tools | HP Driver Packs; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client Catalog; HP Manageability Integration Kit Gen3 |
| HP segment | Business |
| HP speaker type | HP Quad Speakers |
| Other features | |
| Display diagonal (metric) | 33.8 cm |
| Anti-glare screen | Y |
| Harmonized System (HS) code | 84713000 |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
