HP EliteBook 745 G6 - 7DB46AW#UUG
HP EliteBook 745 G6
Product code: 7DB46AW#UUG
- 💻Display diagonal: 14 inch
- 🔳Processor model: 3500U
- 🎫Internal memory: 8 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 256 GB
- ⚖️Weight: 1.53 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Laptop |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 14 inch |
| Dual-screen | No |
| Display brightness | 250 cd/m² |
| Panel type | IPS |
| HD type | Full HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| RGB colour space | NTSC |
| Colour gamut | 45% |
| Native aspect ratio | 16:9 |
| Brand | HP |
| Family | EliteBook |
| Series | 700 |
| Model name | 745 G6 |
| Part Number | 7DB46AW#UUG |
| Release Date | 01 July 2019 |
|
|
|
| Processor | |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen 5 PRO |
| Processor frequency | 2.1 GHz |
| Processor boost frequency | 3.7 GHz |
| Thermal Design Power (TDP) | 15 W |
| Processor model | 3500U |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor cache | 4 MB |
| Processor lithography | 12 nm |
| Processor generation | AMD Ryzen PRO 3000 Series |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 8 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2400 MHz |
| Memory slots | 1x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| ECC | No |
| Graphics | |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | AMD Radeon Vega 8 |
| On-board graphics card base frequency | 1200 MHz |
| Storage | |
| Total storage capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| Total SSDs capacity | 256 GB |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Storage media | SSD |
| Self-Encrypting Drive (SED) | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Wi-Fi | Yes |
| WLAN controller model | Intel Dual Band Wireless-AC 9260 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI version | 2.0 |
| USB Sleep-and-Charge ports | 1 |
| Docking connector | Yes |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Sleep-and-Charge | Yes |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Bang & Olufsen |
| Number of microphones | 3 |
| Camera | |
| Front camera | Yes |
| Infrared (IR) camera | Yes |
| Front camera HD type | HD |
| Front camera signal format | 720p |
| Keyboard | |
| Numeric keypad | No |
| Spill-resistant keyboard | Yes |
| Full-size keyboard | Yes |
| Keyboard layout | AZERTY |
| Keyboard backlit | Yes |
| Pointing device | Clickpad |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
| Battery capacity | 50 Wh |
| Weight & dimensions | |
| Weight | 1.53 kg |
| Height | 17.9 mm |
| Depth | 234.3 mm |
| Width | 326 mm |
| Power | |
| AC adapter power | 65 W |
| Security | |
| Password protection | Yes |
| Brand-specific features | |
| HP segment | Business |
| HP speaker type | HP Dual Speakers |
| HP front camera | HP Webcam HD IR |
| Other features | |
| Display diagonal (metric) | 35.6 cm |
| Anti-glare screen | Yes |
| Harmonized System (HS) code | 84713000 |
