DELL XPS 15 9560 - 9560-4575
DELL XPS 15 9560
Product code: 9560-4575
- 💻Display diagonal: 15.6 inch
- 🔳Processor model: i7-7700HQ
- 🎫Internal memory: 16 GB
- 🎮On-board graphics adapter model: Intel HD Graphics 630
- 🎮Discrete graphics adapter model: NVIDIA GeForce GTX 1050
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 1.8 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black, Silver |
| Product type | Notebook |
| Form factor | Clamshell |
| Market positioning | Business |
| Housing material | Aluminium, Carbon fibre |
| Display | |
| Display diagonal | 15.6 inch |
| Dual-screen | N |
| Display bezel technology | InfinityEdge |
| Pixel pitch | 0.18 x 0.18 mm |
| Display brightness | 350 cd/m² |
| Panel type | IPS |
| Aspect ratio | 16:9 |
| HD type | Full HD |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Brand | DELL |
| Family | XPS |
| Series | 15 |
| Model name | 9560 |
| Part Number | 9560-4575 |
| Release Date | 01 April 2017 |
| EAN/UPC code | 5397063954575 |
| Price | About 1977 USD |
|
|
|
| Processor | |
| Processor series | Intel Core i7-7700 Mobile Series |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor frequency | 2.8 GHz |
| Motherboard chipset | Intel HM175 |
| Processor boost frequency | 3.8 GHz |
| Processor codename | Kaby Lake |
| Thermal Design Power (TDP) | 45 W |
| Processor model | i7-7700HQ |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor cache | 6 MB |
| Processor lithography | 14 nm |
| Processor generation | 7th gen Intel Core i7 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2400 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Maximum internal memory (64-bit) | 32 GB |
| Memory upgrade note | Additional memory sold separately |
| Graphics | |
| On-board graphics adapter | Y |
| Number of discrete graphics adapters installed | 1 |
| NVIDIA G-SYNC | Y |
| NVIDIA GameWorks VR | N |
| CUDA | Y |
| CUDA cores | 640 |
| Discrete graphics memory type | GDDR5 |
| On-board graphics adapter DirectX version | 12.0 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel HD Graphics 630 |
| Discrete graphics adapter model | NVIDIA GeForce GTX 1050 |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| Discrete graphics adapter memory | 4 GB |
| On-board graphics card | Y |
| Discrete graphics card | Y |
| Discrete graphics card model | NVIDIA GeForce GTX 1050 |
| On-board graphics card model | Intel HD Graphics 630 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x591B |
| Discrete graphics card memory | 4 GB |
| Number of discrete graphics cards installed | 1 |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 3.0 |
| SSD form factor | M.2 |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Y |
| Storage media | SSD |
| Optical drive | |
| Optical drive type | N |
| Networking | |
| Ethernet LAN | N |
| Wi-Fi | Y |
| WLAN controller model | Killer Wireless-AC 1535 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 4.1 |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Number of Thunderbolt 3 ports with PowerShare support | 1 |
| PowerShare | Y |
| Number of USB ports with PowerShare support | 2 |
| USB Power Delivery revision | 2.0 |
| USB Power Delivery | Y |
| Charging port type | DC-in jack |
| HDMI version | 1.4 |
| USB Sleep-and-Charge ports | 2 |
| DVI port | N |
| Docking connector | N |
| Combo headphone/mic port | Y |
| HDMI ports quantity | 1 |
| USB Sleep-and-Charge | Y |
| Audio | |
| Built-in microphone | Y |
| Number of built-in speakers | 2 |
| Audio system | MaxxAudio Pro |
| Speaker power | 2 W |
| Audio chip | Realtek ALC3266 |
| Speakers manufacturer | Waves |
| Camera | |
| Front camera | Y |
| Front camera HD type | HD |
| Wide-angle lens front camera | Y |
| Video capturing speed | 30 fps |
| Front camera resolution | 1280 x 720 pixels |
| Front camera signal format | 720p |
| Front camera resolution (numeric) | 0.9 MP |
| Keyboard | |
| Numeric keypad | N |
| Palmrest keyboards supported | Belgian, Czech, French, German, International EER+North Sea, Italian, Portuguese, Slovakian, Spanish, Swiss, Turkish |
| Full-size keyboard | Y |
| Keyboard backlit | Y |
| Windows keys | Y |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 10 Home |
| Pre-installed software | Skype, Microsoft Edge, Dropbox |
| Operating system language | German, Dutch, English, French, Italian |
| Operating system architecture | 64-bit |
| Drivers included | Y |
| Bundled software | Financial Tracker & Retail Information Additional Software (Win10) |
| Trial software | McAfee LiveSafe (30 days Trial), Microsoft Office (30 days Trial - Excludes Office License) |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery charge status button | Y |
| Battery charge indicator | Y |
| Battery recharge time | 4 h |
| Number of battery cells | 6 |
| Battery life (max) | 19.5 h |
| Battery capacity | 97 Wh |
| Battery capacity (Watt hours) | 97 Wh |
| Battery voltage | 11.4 V |
| Weight & dimensions | |
| Weight | 1.8 kg |
| Height (rear) | 1.7 cm |
| Height (front) | 1.1 cm |
| Depth | 235 mm |
| Width | 357 mm |
| Power | |
| AC adapter power | 130 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 6.67 A |
| Security | |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Fingerprint reader | N |
| Trusted Platform Module (TPM) | Y |
| Password protection | Y |
| Password protection type | BIOS, Supervisor, User |
