Product code: V1JC5
As an Amazon Associate I earn from qualifying purchases.
Design | |
---|---|
Product colour | Black |
Colour of product | Black |
Product type | Mobile workstation |
Form factor | Clamshell |
Market positioning | Business |
Display | |
Display diagonal | 15.6 inch |
Pixel density | 141 ppi |
Contrast ratio (typical) | 700:1 |
Pixel pitch | 0.179 x 0.179 mm |
Panel type | IPS |
Display surface | Matt |
Aspect ratio | 16:9 |
HD type | Full HD |
LED backlight | Y |
Touchscreen | N |
Display resolution | 1920 x 1080 pixels |
Native aspect ratio | 16:9 |
Brand | DELL |
Family | Precision |
Series | 7000 |
Model name | 7530 |
Part Number | V1JC5 |
Release Date | 12 September 2018 |
EAN/UPC code | 5397184189894 |
|
|
Processor | |
Processor manufacturer | Intel |
Processor family | Intel Core i7 |
Processor frequency | 2.2 GHz |
Motherboard chipset | Intel CM246 |
Processor boost frequency | 4.1 GHz |
Processor codename | Coffee Lake |
Thermal Design Power (TDP) | 45 W |
Processor model | i7-8750H |
Processor cores | 6 |
Processor threads | 12 |
Processor cache | 9 MB |
Processor lithography | 14 nm |
Processor socket | BGA 1440 |
Processor generation | 8th gen Intel Core i7 |
Memory | |
Internal memory type | DDR4-SDRAM |
Internal memory | 16 GB |
Memory form factor | SO-DIMM |
Memory clock speed | 2666 MHz |
Memory slots | 4x SO-DIMM |
Maximum internal memory | 128 GB |
Memory layout (slots x size) | 2 x 8 GB |
Maximum internal memory (64-bit) | 128 GB |
Memory upgrade note | Additional memory sold separately |
Graphics | |
On-board graphics adapter | Y |
Number of discrete graphics adapters supported | 1 |
On-board graphics adapter family | Intel UHD Graphics |
Number of discrete graphics adapters installed | 1 |
Maximum resolution | 7680 x 4320 pixels |
Discrete graphics memory type | GDDR5 |
On-board graphics adapter DirectX version | 12.0 |
Discrete graphics adapter | Y |
On-board graphics adapter model | Intel UHD Graphics 630 |
Discrete graphics adapter model | NVIDIA Quadro P1000 |
On-board graphics adapter base frequency | 350 MHz |
On-board graphics adapter dynamic frequency (max) | 1100 MHz |
Maximum on-board graphics adapter memory | 64 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter OpenGL version | 4.5 |
Discrete graphics adapter memory | 4 GB |
On-board graphics card | Y |
Discrete graphics card | Y |
Discrete graphics card model | NVIDIA Quadro P1000 |
On-board graphics card model | Intel UHD Graphics 630 |
On-board graphics card family | Intel UHD Graphics |
On-board graphics card base frequency | 350 MHz |
On-board graphics card dynamic frequency (max) | 1100 MHz |
Maximum on-board graphics card memory | 64 GB |
On-board graphics card DirectX version | 12.0 |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card ID | 0x3E9B |
Discrete graphics card memory | 4 GB |
Number of discrete graphics cards supported | 1 |
Number of discrete graphics cards installed | 1 |
Storage | |
Total storage capacity | 256 GB |
Number of SSDs installed | 1 |
SSD capacity | 256 GB |
SSD interface | PCI Express 3.0 |
SSD form factor | M.2 |
Compatible memory cards | SD, SDHC, SDXC |
Solid-state drive interface | PCI Express 3.0 |
Solid-state drive capacity | 256 GB |
Card reader integrated | Y |
Storage media | SSD |
Optical drive | |
Optical drive type | N |
Networking | |
Ethernet LAN | Y |
Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
Wi-Fi | Y |
WLAN controller model | Intel Dual Band Wireless-AC 9260 |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Wi-Fi data rate (max) | 1733 Mbit/s |
Antenna type | 2x2 |
MIMO | Y |
MIMO type | Multi User MIMO |
Bluetooth | Y |
Bluetooth version | 5.0 |
4G | N |
3G | N |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
PowerShare | Y |
Number of USB ports with PowerShare support | 2 |
Charging port type | DC-in jack |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
On/off button | Y |
HDMI version | 2.0 |
SmartCard slot | Y |
Docking connector | Y |
Combo headphone/mic port | Y |
DC-in jack | Y |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Thunderbolt 3 ports quantity | 2 |
Mini DisplayPorts quantity | 1 |
Audio | |
Number of built-in speakers | 2 |
Speaker power | 2 W |
Audio chip | Realtek ALC3281 |
Camera | |
Front camera | Y |
Front camera HD type | HD |
Video capturing speed | 30 fps |
Front camera resolution | 1280 x 720 pixels |
Front camera signal format | 720p |
Front camera resolution (numeric) | 0.92 MP |
Keyboard | |
Numeric keypad | Y |
Keyboard backlit | Y |
Windows keys | Y |
Pointing device | Touchpad |
Performance | |
Virtual Reality (VR) ready | Y |
Software | |
Operating system installed | Windows 10 Pro |
Operating system language | Multilingual |
Operating system architecture | 64-bit |
Battery | |
Battery technology | Lithium-Ion (Li-Ion) |
Battery weight | 298 g |
Battery recharge time | 4 h |
Number of battery cells | 4 |
Battery capacity | 64 Wh |
Battery capacity (Watt hours) | 64 Wh |
Battery voltage | 7.8 V |
Weight & dimensions | |
Weight | 2.52 kg |
Height (rear) | 3 cm |
Height (front) | 2.5 cm |
Depth | 251.3 mm |
Width | 377.6 mm |
Power | |
AC adapter power | 180 W |
AC adapter frequency | 50 - 60 Hz |
AC adapter input voltage | 100 - 240 V |
AC adapter output voltage | 19.5 V |
AC adapter output current | 9.23 A |
Security | |
Cable lock slot | Y |
Cable lock slot type | Noble |
Trusted Platform Module (TPM) | Y |
Password protection | Y |
