DELL G5 5505 - J1PPW
DELL G5 5505
Product code: J1PPW
- 💻Display diagonal: 15.6 inch
- 🔳Processor model: 4600H
- 🎫Internal memory: 8 GB
- 🎮On-board graphics adapter model: AMD Radeon Graphics
- 🎮Discrete graphics adapter model: AMD Radeon RX 5600M
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 2.5 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Grey |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Display | |
| Display diagonal | 15.6 inch |
| Maximum refresh rate | 120 Hz |
| Display brightness | 250 cd/m² |
| Panel type | WVA |
| Aspect ratio | 16:9 |
| HD type | Full HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Brand | DELL |
| Family | G5 |
| Model name | 5505 |
| Part Number | J1PPW |
| Release Date | 04 July 2020 |
| EAN/UPC code | 5397184472101 |
|
|
|
| Processor | |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen 5 |
| Processor frequency | 3 GHz |
| Processor boost frequency | 4 GHz |
| Processor model | 4600H |
| Processor cores | 6 |
| Processor cache | 8 MB |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 8 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 3200 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 2 x 4 GB |
| Graphics | |
| On-board graphics adapter | Y |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | AMD Radeon Graphics |
| Discrete graphics adapter model | AMD Radeon RX 5600M |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Radeon RX 5600M |
| On-board graphics card model | AMD Radeon Graphics |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | NVMe, PCI Express |
| SSD form factor | M.2 |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Yes |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| WLAN controller model | Killer Wireless-AX 1650 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Charging port type | DC-in jack |
| HDMI version | 2.0 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Mini DisplayPorts quantity | 1 |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Nahimic 3D |
| Speaker power | 2 W |
| Audio chip | Realtek ALC3254 |
| Camera | |
| Front camera | Yes |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Front camera resolution | 1280 x 720 pixels |
| Front camera resolution (numeric) | 0.92 MP |
| Keyboard | |
| Numeric keypad | Yes |
| Full-size keyboard | Yes |
| Keyboard layout | QWERTY |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard language | Nordic |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system language | Norwegian |
| Operating system architecture | 64-bit |
| Bundled software | Financial Tracker & Retail Information |
| Battery | |
| Battery weight | 210 g |
| Battery capacity (Watt-hours) | 51 Wh |
| Battery recharge time | 4 h |
| Number of battery cells | 3 |
| Battery capacity | 51 Wh |
| Battery voltage | 11.4 V |
| Weight & dimensions | |
| Weight | 2.5 kg |
| Height (rear) | 2.66 cm |
| Height (front) | 2.16 cm |
| Depth | 254 mm |
| Width | 364.5 mm |
| Power | |
| AC adapter power | 240 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 12.31 A |
| Security | |
| Cable lock slot | Yes |
| Password protection | Yes |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
