ASUS VivoBook 15 X540UA-GQ964R - 90NB0HF1-M13700

ASUS VivoBook 15 X540UA-GQ964R

Product code: 90NB0HF1-M13700

  • đŸ’ģDisplay diagonal: 15.6 inch
  • đŸ”ŗProcessor model: i3-7020U
  • đŸŽĢInternal memory: 8 GB
  • 🎮On-board graphics adapter model: Intel HD Graphics 620
  • 🎮Discrete graphics adapter model: Not available
  • đŸ’ŊTotal storage capacity: 256 GB
  • ⚖ī¸Weight: 2 kg
📊 Add to compare

As an Amazon Associate I earn from qualifying purchases.

Specifications
Design
Product colourBlack, Chocolate
Product typeNotebook
Form factorClamshell
Display
Display diagonal15.6 inch
Aspect ratio16:9
HD typeHD
LED backlightY
TouchscreenN
Display resolution1366 x 768 pixels
Native aspect ratio16:9
BrandASUS
FamilyVivoBook
Series15
Model nameX540UA-GQ964R
Part Number90NB0HF1-M13700
Release Date19 September 2018
EAN/UPC code4718017116060
Processor
Processor manufacturerIntel
Processor familyIntel Core i3
Processor frequency2.3 GHz
Processor codenameKaby Lake
Thermal Design Power (TDP)15 W
Processor modeli3-7020U
Processor cores2
Processor threads4
Processor cache3 MB
Processor lithography14 nm
Processor socketBGA 1356
Processor generation7th gen Intel Core i3
Memory
Internal memory typeDDR4-SDRAM
Internal memory8 GB
Memory form factorOn-board + SO-DIMM
Memory clock speed2133 MHz
Memory slots1x SO-DIMM
Maximum internal memory12 GB
Maximum internal memory (64-bit)12 GB
Graphics
On-board graphics adapterY
On-board graphics adapter 4K supportY
On-board graphics adapter familyIntel HD Graphics
Graphics adapter Open GL supportY
Discrete graphics adapterN
On-board graphics adapter modelIntel HD Graphics 620
Discrete graphics adapter modelNot available
On-board graphics cardY
Discrete graphics cardN
Discrete graphics card modelNot available
On-board graphics card modelIntel HD Graphics 620
On-board graphics card familyIntel HD Graphics
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Maximum on-board graphics card memory32 GB
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x5916
On-board graphics card 4K supportY
Graphics card Open GL supportY
Storage
Total storage capacity256 GB
Number of SSDs installed1
SSD capacity256 GB
SSD interfaceSATA III
Compatible memory cardsMicroSD (TransFlash)
Solid-state drive interfaceSerial ATA III
Solid-state drive capacity256 GB
Card reader integratedY
Storage mediaSSD
Optical drive
Optical drive typeDVD Super Multi
Networking
Ethernet LANN
Wi-FiY
BluetoothY
Bluetooth version4.0
4GN
3GN
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Charging port typeDC-in jack
USB 3.0 (3.1 Gen 1) Type-A ports quantity1
ExpressCard slotN
Combo headphone/mic portY
USB 2.0 ports quantity2
HDMI ports quantity1
Audio
Built-in microphoneY
Number of built-in speakers2
Audio systemSonicMaster
Speaker power2 W
Camera
Front cameraY
Keyboard
Numeric keypadY
Island-style keyboardY
Full-size keyboardY
Windows keysY
Pointing deviceTouchpad
Software
Operating system installedWindows 10 Pro
Battery
Number of battery cells3
Battery capacity33 Wh
Battery capacity (Watt hours)33 Wh
Weight & dimensions
Weight2 kg
Height27.2 mm
Depth251 mm
Width381 mm
Power
AC adapter power45 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output voltage19 V
AC adapter output current2.37 A
Security
Cable lock slotY
Password protectionY
Password protection typeBIOS, User
