Product code: 90NR0EP1-M00680
As an Amazon Associate I earn from qualifying purchases.
Design | |
---|---|
Product colour | Black, Sand |
Product type | Notebook |
Form factor | Clamshell |
Market positioning | Gaming |
Display | |
Display diagonal | 16 inch |
Maximum refresh rate | 165 Hz |
Contrast ratio (typical) | 1000:1 |
Display brightness | 250 cd/m² |
Panel type | IPS |
HD type | WUXGA |
Touchscreen | N |
Display resolution | 1920 x 1200 pixels |
RGB colour space | NTSC |
Colour gamut | 72% |
Native aspect ratio | 16:10 |
Brand | ASUS |
Family | TUF Gaming |
Series | A16 Advantage Edition |
Model name | FA617NS-N3085W |
Part Number | 90NR0EP1-M00680 |
Release Date | 10 February 2023 |
EAN/UPC code | 4711387033876 |
|
|
Processor | |
Processor manufacturer | AMD |
Processor family | AMD Ryzen 7 |
Processor frequency | 3.2 GHz |
Processor boost frequency | 4.75 GHz |
Processor model | 7735HS |
Processor cores | 8 |
Processor cache | 20 MB |
Memory | |
Internal memory type | DDR5-SDRAM |
Internal memory | 16 GB |
Memory form factor | SO-DIMM |
Memory clock speed | 4800 MHz |
Memory slots | 2x SO-DIMM |
Maximum internal memory | 32 GB |
Memory layout (slots x size) | 2 x 8 GB |
Graphics | |
Discrete graphics memory type | GDDR6 |
Discrete GPU manufacturer | AMD |
On-board graphics card | Y |
Discrete graphics card | Y |
Discrete graphics card model | AMD Radeon RX 7600S |
On-board graphics card model | AMD Radeon 680M |
Discrete graphics card memory | 8 GB |
Storage | |
Total storage capacity | 512 GB |
Number of SSDs installed | 1 |
SSD capacity | 512 GB |
Total SSDs capacity | 512 GB |
SSD interface | PCI Express 4.0 |
SSD form factor | M.2 |
Storage media | SSD |
NVMe | Y |
Optical drive | |
Optical drive type | N |
Networking | |
Ethernet LAN | Y |
Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi standards | Wi-Fi 6 (802.11ax) |
Antenna type | 2x2 |
Bluetooth | Y |
Bluetooth version | 5.2 |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
USB Power Delivery | Y |
HDMI version | 2.1 |
Combo headphone/mic port | Y |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB Type-C DisplayPort Alternate Mode | Y |
Audio | |
Built-in microphone | Y |
Number of built-in speakers | 2 |
Audio system | Dolby Atmos |
Camera | |
Front camera | Y |
Front camera HD type | HD |
Keyboard | |
Numeric keypad | Y |
Island-style keyboard | Y |
Keyboard layout | QWERTY |
Keyboard backlit | Y |
Pointing device | Touchpad |
Keyboard language | Dutch |
Software | |
Operating system installed | Windows 11 Home |
Operating system architecture | 64-bit |
Battery | |
Battery technology | Lithium-Ion (Li-Ion) |
Number of battery cells | 4 |
Battery capacity | 90 Wh |
Weight & dimensions | |
Weight | 2.2 kg |
Height (rear) | 2.68 cm |
Height (front) | 2.21 cm |
Depth | 252 mm |
Width | 355 mm |
Power | |
AC adapter power | 240 W |
AC adapter frequency | 50 - 60 Hz |
AC adapter input voltage | 100 - 240 V |
AC adapter output voltage | 20 V |
AC adapter output current | 12 A |
Security | |
Cable lock slot | Y |
Cable lock slot type | Kensington |
Other features | |
Anti-glare screen | Y |
