ASUS Zenbook Flip 15 OLED UX564EI-H2005T - 90NB0SB1-M00870
ASUS Zenbook Flip 15 OLED UX564EI-H2005T
Product code: 90NB0SB1-M00870
- 💻Display diagonal: 15.6 inch
- 🔳Processor model: i7-1165G7
- 🎫Internal memory: 16 GB
- 🎮On-board graphics adapter model: Intel Iris Xe Graphics
- 🎮Discrete graphics adapter model: NVIDIA GeForce GTX 1650 Ti Max-Q
- 💽Total storage capacity: 1 TB
- ⚖️Weight: 1.9 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Grey |
| Product type | Hybrid (2-in-1) |
| Form factor | Convertible (Folder) |
| Market positioning | Home |
| Display | |
| Display diagonal | 15.6 inch |
| Display brightness | 400 cd/m² |
| Panel type | OLED |
| Display surface | Gloss |
| HD type | 4K Ultra HD |
| LED backlight | Yes |
| Touchscreen | Yes |
| Display resolution | 3840 x 2160 pixels |
| RGB colour space | DCI-P3 |
| Colour gamut | 100% |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Family | Zenbook |
| Series | Flip 15 OLED |
| Model name | UX564EI-H2005T |
| Part Number | 90NB0SB1-M00870 |
| Release Date | 14 January 2021 |
| EAN/UPC code | 4718017993203 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor boost frequency | 4.7 GHz |
| Processor model | i7-1165G7 |
| Processor cores | 4 |
| Processor cache | 12 MB |
| Configurable TDP-up frequency | 2.8 GHz |
| Configurable TDP-up | 28 W |
| Processor generation | 11th gen Intel Core i7 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | On-board |
| Maximum internal memory | 16 GB |
| Graphics | |
| On-board graphics adapter | Y |
| NVIDIA Max-Q | Yes |
| On-board graphics adapter family | Intel Iris Graphics |
| Discrete graphics memory type | GDDR6 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel Iris Xe Graphics |
| Discrete graphics adapter model | NVIDIA GeForce GTX 1650 Ti Max-Q |
| Discrete graphics adapter memory | 4 GB |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce GTX 1650 Ti Max-Q |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board graphics card family | Intel Iris Graphics |
| Discrete graphics card memory | 4 GB |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| SSD form factor | M.2 |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Storage media | SSD |
| Intel® Optane™ Memory module installed | Yes |
| Intel® Optane™ Memory module capacity | 32 GB |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | No |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Charging port type | DC-in jack |
| HDMI version | 2.0b |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| USB4 Gen 3x2 ports quantity | 2 |
| Audio | |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Windows Hello | Yes |
| Infrared (IR) camera | Yes |
| Front camera HD type | HD |
| Keyboard | |
| Numeric keypad | Yes |
| Keyboard layout | QWERTY |
| Pointing device | Touchpad |
| Keyboard language | US International |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity (Watt-hours) | 96 Wh |
| Number of battery cells | 6 |
| Battery capacity | 96 Wh |
| Weight & dimensions | |
| Weight | 1.9 kg |
| Height | 19.9 mm |
| Depth | 230.8 mm |
| Width | 356 mm |
| Power | |
| AC adapter power | 120 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 20 V |
| AC adapter output current | 6 A |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
